How to install GST fire alarm properly to avoid false alarms

NGÀY ĐĂNG 18/09/2025

Admin

"It seems simple, but if you install it wrongly, the fire alarm may not ring!"
This small device is the first "warning bell" when there is a fire. But do you know how to install it correctly, in the right place and according to the right standards to ensure the bell works effectively?

GST fire alarm and its outstanding advantages

GST fire alarm is a device in the automatic fire alarm system, often manufactured by the GST brand (Guangzhou Shengting Electronics Co., Ltd.) - a Chinese company specializing in fire protection equipment (PCCC). This device has the function of emitting a warning sound (bell or siren) when the fire alarm system detects smoke, heat or an activation signal from the emergency button.

Outstanding advantages of GST fire alarm:

• Loud and clear sound, easy to recognize in crowded environments.
• Low power consumption, stable operation.
• Compact design, easy to install on the wall or ceiling.
• Perfectly compatible with GST's conventional and addressable fire alarm systems.
• Meet international fire protection standards such as CCCF, UL.

GST fire alarm bell classification

Classification by system technology

GST fire alarm bell for conventional systems

Features:

• Operating by zone, activated simultaneously when an alarm occurs.
• Directly connected to conventional fire alarm panels.
• Applications: Houses, small shops, small offices.

GST fire alarm bell for addressable systems:

Features:

• Has its own address, controlled independently from the central panel.
• Integrated communication protocol.
• Applications: High-rise buildings, hospitals, shopping malls.

For example: GST-HX-100A: Addressable fire alarm speaker, voice support (EVAC).

Classification by design & sound

Mechanical bells (Bells)

Features:

• Continuous sound ("ring-ring").
• Usually used for conventional systems.

Speakers

Features:

• Emits a fixed frequency sound (e.g. "beep") or voice announcement.
• For both conventional and addressable systems.

Example: GST-HX-200B: Speaker with strobe light, integrated voice announcement.

Sound & Visual Alarms

Features:

• Combines sound + flash light to warn the hearing impaired.
• Often used in hospitals, shopping malls.

Example: GST-LED-100 (100dB sound + red LED).

Classification by voltage & capacity

24VDC fire alarm bell

• Standard voltage in fire alarm system
• Compatible with most GST fire alarm panels and many other brands

Example: GST I-9403

12VDC fire alarm bell

• Used in small systems or special systems
• Often appears in compact security alarm systems
• Classification by usage environment
• Standard bell (Indoor): Used indoors.
• Waterproof bell (Waterproof/IP65): Installed outdoors, in wet areas.

Explosion-Proof bell (Explosion-Proof): Used for chemical plants, oil depots.

How to install a fire alarm bell

Step 1: Determine the appropriate location for the bell

• Choose a place that is easy to hear, easy to see, airy, and not blocked by sound or flashing lights (if any).
• Ideal location: hallway, near exit, public area.
• Recommended height: 2 – 2.5 meters from the floor.

Step 2: Fix the bell base to the ceiling/wall

Use a drill and screws to firmly attach the bell base to the selected location.

Make sure the fixed surface is flat and not wet.

Step 3: Connect the wires according to the diagram

Connect the 24VDC power source from the fire alarm panel to the bell.

Ensure the correct polarity (+/-) if it is a conventional bell.

For addressable bells (such as GST I-9403), it is necessary to connect an additional loop signal wire and set the address using a programming device.

Step 4: Attach the bell body to the base

After completing the wiring, insert the bell body into the base and screw it in place according to the manufacturer's instructions.

Step 5: Check and test the system

Supply power to the fire alarm system.

Perform a test fire alarm activation (by switch, detector simulation, etc.) to check:

• The bell rings at the correct intensity.
• Flashing light (if any) is bright.
• No short circuit or system error.
