36U Rack Cabinet D800 SR36880BVA3-FAN
With a compact, space-saving design, the SR36880BVA3-FAN cabinet is an ideal choice for small-scale enterprise and data center networks. The depth of 800mm makes the cabinet suitable for telecommunications equipment, switches, routers and patch panels without taking up too much space.
The cabinet is equipped with flexible adjustable equipment mounting bars, allowing for quick installation. The cooling fan system and mesh doors help ensure the equipment operates durably without being affected by high temperatures.
Specifications
- Dimensions (WxDxH): 800 x 800 x 1780 mm
- Usable height: 36U
- Static load: 1500 kg
- Front & rear doors: 75% honeycomb mesh, security lock
- Cooling system: 4 standard fans
- Material: SPCC steel, RAL 9005 powder coating
- Standards: DIN 41494, UL 60950-1, IEC 297-2
SmartRak 3.0 Ordering Information
| (U) | 600 x 600 | 600 x 800 | 600 x 1000 | 600 x 1100 | 600 x 1200 | 800 x 600 | 800 x 800 | 800 x 1000 | 800 x 1100 |
800 x 1200
|
|---|
| 27U |
SR27660BVA3-FAN |
SR27680BVA3-FAN |
SR27610BVA3-FAN |
SR27611BVA3-FAN |
SR27612BVA3-FAN |
SR27860BVA3-FAN |
SR27880BVA3-FAN |
SR27810BVA3-FAN |
SR27811BVA3-FAN |
SR27812BVA3-FAN |
| 32U |
SR32660BVA3-FAN |
SR32680BVA3-FAN |
SR32610BVA3-FAN |
SR32611BVA3-FAN |
SR32612BVA3-FAN |
SR32860BVA3-FAN |
SR32880BVA3-FAN |
SR32810BVA3-FAN |
SR32811BVA3-FAN |
SR32812BVA3-FAN |
| 36U |
SR36660BVA3-FAN |
SR36680BVA3-FAN |
SR36610BVA3-FAN |
SR36611BVA3-FAN |
SR36612BVA3-FAN |
SR36860BVA3-FAN |
SR36880BVA3-FAN |
SR36810BVA3-FAN |
SR36811BVA3-FAN |
SR36812BVA3-FAN |
| 42U |
SR42660BVA3-FAN |
SR42680BVA3-FAN |
SR42610BVA3-FAN |
SR42611BVA3-FAN |
SR42612BVA3-FAN |
SR42860BVA3-FAN |
SR42880BVA3-FAN |
SR42810BVA3-FAN |
SR42811BVA3-FAN |
SR42812BVA3-FAN |
| 45U |
SR45660BVA3-FAN |
SR45680BVA3-FAN |
SR45610BVA3-FAN |
SR45611BVA3-FAN |
SR45612BVA3-FAN |
SR45860BVA3-FAN |
SR45880BVA3-FAN |
SR45810BVA3-FAN |
SR45811BVA3-FAN |
SR45812BVA3-FAN |
| 47U |
SR47660BVA3-FAN |
SR47680BVA3-FAN |
SR47610BVA3-FAN |
SR47611BVA3-FAN |
SR47612BVA3-FAN |
SR47860BVA3-FAN |
SR47880BVA3-FAN |
SR47810BVA3-FAN |
SR47811BVA3-FAN |
SR47812BVA3-FAN |
| 48U |
SR48660BVA3-FAN |
SR48680BVA3-FAN |
SR48610BVA3-FAN |
SR48611BVA3-FAN |
SR48612BVA3-FAN |
SR48860BVA3-FAN |
SR48880BVA3-FAN |
SR48810BVA3-FAN |
SR48811BVA3-FAN |
SR48812BVA3-FAN |
| 50U |
SR50660BVA3-FAN |
SR50680BVA3-FAN |
SR50610BVA3-FAN |
SR50611BVA3-FAN |
SR50612BVA3-FAN |
SR50860BVA3-FAN |
SR50880BVA3-FAN |
SR50810BVA3-FAN |
SR50811BVA3-FAN |
SR50812BVA3-FAN |
| 52U |
SR52660BVA3-FAN |
SR52680BVA3-FAN |
SR52610BVA3-FAN |
SR52611BVA3-FAN |
SR52612BVA3-FAN |
SR52860BVA3-FAN |
SR52880BVA3-FAN |
SR52810BVA3-FAN |
SR52811BVA3-FAN |
SR52812BVA3-FAN |
|
