B6800-LIC-500 Bosch 500 Account Extension License

B6800-LIC-500 Bosch 500 Account Extension License

Bosch B6800-LIC-500 is a 500-account license expansion package for the Bosch B6800-SR CONETTIX central signal receiving software. This package allows you to increase the number of monitoring accounts on your existing system, meeting the need to expand the scale of your monitoring center flexibly and effectively.

Outstanding features:

• Standard browser-based graphical user interface allows simple and secure operation for concurrent multiple users
• Directly manage multiple virtual receivers simultaneously
• Dashboard monitoring of account status, event traffic, and notifications
• UL certified automated failover ensures no missed events
• Flexible licensing effectively meets operational needs

Technical specifications

• Processor: Intel Core I7 10th generation or higher

• RAM: 16 GB

• Storage: 500 GB

• Ethernet ports: 1 port required, 1000 Mbps capable

• Operating system: Windows 10 (version 22H2 or higher), Windows Server 2019 or 2022

• Account capacity for B6800-SR system: Maximum of 10,500 accounts

• Virtual receivers for B6800-SR system: 2 receivers provided and installed with system

• Account licenses: 500, 2500, 10,000 accounts (all licenses can be combined, up to 10,500 accounts)

• Input IP protocol: CONETTIX

• Input message formats (via IP): Bosch Modem (IIe, IIIa2, IV), Contact ID, SIA DC-03, Pulse 3/1, 4/2

• Output to automation:

  • Output protocols: 6500 Mode, Bosch SIA Mode

  • Supports unique automation output for each virtual receiver

• Security:

  • Encryption description: NIST AES 128, 192, 256

  • Anti-substitution/Anti-replay protection

  • Denial of service (DoS) protection
