AC-EC2128-8RH Elevator Control Module
- Product Code: AC-EC2128-8RH
- Product Series: Elevator Controller
- Manufacturer: CNB
- Warranty: ** months
AC-EC2128-8RH Elevator Control Module
The AC-EC2128-8RH is an elevator control module that allows integration of a CNB intercom system with the elevator control system to enhance security control and access control.
The device controls elevator access via a door station (doorbell) or indoor monitor, ensuring only authorized personnel can access specific floors.
Thanks to its flexible integration capabilities, this module enhances the safety of buildings such as apartment buildings, office buildings, and hotels, while also managing elevator movement efficiently and securely.
Features
- Enables visitors to access to authorized floor only
- Enables household to summon the elevator on indoor monitor
- PoE or DC 24V power supply
Specifications
| AC-EC2128-8RH | |
| Physical | |
| Material | Plastic |
| Power Supply | PoE or DC 24V/0.3A power supply |
| Standby Power | 4W |
| Max Power (NC) | 7W |
| Mini Power (NO) | 1W |
| Ethernet Port | 1 x RJ45, 10/100 Mbps adaptive |
| Control Method | Relay |
| Relay | 16 Channels |
| Firmware Upgrade | Ethernet/USB |
| Working Temperature | -40℃ ~ +55℃ |
| Storage Temperature | -10℃ ~ +70℃ |
| Working Humidity | 10% ~ 90% (non-condensing) |
